AdTech Using three-dimensional network structure and connected pores organic foam as a carrier and immerse into thixotropic special Al2O3 molten material slurry, using four correction center distance and automatic extrusion, the slurry evenly deposited in the foam, after 1320 ℃ Drying and solidification.
AdTech Using three-dimensional network structure and connected pores organic foam as a carrier and immerse into thixotropic special Al2O3 molten material slurry, using four correction center distance and automatic extrusion, the slurry evenly deposited in the foam, after 1320 ℃ Drying and solidification.
Product Description
- 3D reticulate structure
- High mechanical strength, no-dregs off when flapping
- High porosity
- Large surface areas, strong absorptivity of impurities
- Excellent thermal shock resistance
- Rapid improvement in filed
Application
Filter-PAl ceramic foam filter can effectively remove and absorb large or small impurities in molten aluminum, improve the surface quality, product performance and microstructure effectiveness. Mainly used in the domestic, construction, electricity, condensing tubes, cable and other aluminum alloy precision casting.
Performance
Filter-PAl ceramic foam filter can effectively remove and absorb large or small impurities in molten aluminum, improve the surface quality, product performance and microstructure effectiveness. Mainly used in the domestic, construction,
electricity, condensing tubes, cable and other aluminum alloy precision casting.
Product Feature
- Aluminum alloy bar choose: 10-30ppi
- Long-term casting choose: 30-50ppi
- High quality aluminum profile or plate choose :40 or 50ppi
- Double zero wave continuous casting and rolling choose: >50ppi
- Other specifications can be customized as your requirments
Product Parameter
| Specifications | Aluminum flow range | Filtration Flow | Aperture |
| mm(inch) | ( kg/min) | ( Ton ) | (ppi) |
| 178×178×50mm 7(inch) | 25-50 | 3 | 10-50ppi |
| 254×254×50mm 10(inch) | 45-100 | 7 | 10-50ppi |
| 305×305×50mm 12(inch) | 90-170 | 15 | 10-50ppi |
| 381×381×50mm 15(inch) | 147-280 | 20 | 10-50ppi |
| 432×432×50mm 17(inch) | 193-367 | 25 | 10-50ppi |
| 508×508×50mm 20(inch) | 274-521 | 30 | 10-50ppi |
| 584×584×50mm 23(inch) | 369-700 | 35 | 10-50ppi |
Technical parameters
| Index | Density (g. cm3) |
Rupture modulus (816℃ Mpa) |
Compressive strength（Mpa） |
Operating temperature(MAX) (℃) |
|
| Item | 0.52 | 4.8 | 0.51 | 1280 | |
| Pore size | |||||
| Type（ppi） | 10 | 20 | 30 | 40 | 50 |
| Pore | 8- 12 | 18- 22 | 28- 32 | 38-42 | 48- 52 |
| average size（um） | 2000 | 840 | 590 | 420 | 297 |
| Data of application | |||||
| Product Specifications(mm) |
Effective Filtration area(％) |
Filtration flow Range（kg/min） |
|||
| 7in(178*178*50) | 68 | 22-42 | |||
| 9in(229*229*50) | 70 | 42-68 | |||
| 12in(305*305*50) | 73 | 60-135 | |||
| 15in(381*381*50) | 79 | 90-240 | |||
| 17in(432*432*50) | 80 | 125- 310 | |||
| 20in(508*508*50) | 82 | 170-420 | |||
| 23in(584*584*50) | 84 | 230-580 |
Usage
- Clean the aluminum filter box, keep it clean and intact.
- Put the ceramic foam filter into filter box carefully , press Sealing gasket around , avoid molten aluminum Dispersing or floating away.
- Use electric or gas to Preheat filter box and ceramic foam filter evenly 15-30min, make the temperature next to the molten aluminum, ceramic foam filter preheating temperature should surpass 460℃.expansion cotton will seal after heating, it makes ceramic foam filter steady in molten aluminum. preheating makes ceramic foam filter pores open and avoid occlusion expansion and contraction.
- Observe change of molten aluminum pressure, control the flowing molten aluminum needed, normal start pressure: 100-150mm. the pressure falls down bellow 75-100mm when molten aluminum flowing, it will grow later.
- Do not shock and beat ceramic foam filter in filtration. Control molten aluminum flow rate in launder.
- Take out ceramic foam filter and clean filter box after filtration.
Storage: stored in ventilated and dry environment.
Package: 5 pieces/ carton, 60 pieces/pallet.
